Default no spark

Old 06-11-2010, 02:32 PM   #1
54cj3b is offline
54cj3b
Jeeper
Vehicle(s): 1954 willys cj3b 1976 dj 5 rhd 1981 dj 5 rhd 1988 xj 1993 xj rhd 2006 kj

54cj3b's Avatar

Join Date: Apr 2010
Location: COLORADO
Age: 50
Posts: 277
Thanks: 0
Thanked 12 Times in 12 Posts
Rep Power: 5 54cj3b is on a distinguished road
76 258 I6 everything was replaced with brand new parts ignition modular, ecm , coil , dist shaft , dist cap/rotor I had it running than it cut out, I get power to coil 12v but nothing from coil to dist not even while cranking went through the wiring with a fine tooth comb but cant find any faulty wires any ideas on what I may have missed checking I'm not the best with electrical ,
My first thought was the cps till I did research finding it didn't have one so that thought went out the window,
__________________




Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiFurl this Post!Stumble this Post!
Reply With Quote
Register as a Member and remove this add!

Vote for Jeep-CJ.com daily!
Vote for Jeep-CJ.com

Default Re: no spark

Old 06-11-2010, 03:14 PM   #2
priceg is offline
priceg
Senior Jeeper
Vehicle(s): 1982 CJ 7 4.2liter T176,D300,D30,AMC20 3inch lift, ARB lockers front and rear, 4.10gears, 33inch tires.

priceg's Avatar

Join Date: May 2010
Location: Tennessee
Posts: 487
Thanks: 8
Thanked 27 Times in 25 Posts
Rep Power: 5 priceg is on a distinguished road
Take a spare spark plug and stick it in your coil wire to see if your coil crapped out. If you have power and ground at the coil, it my have retired.



Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiFurl this Post!Stumble this Post!
Reply With Quote

Default Re: no spark

Old 06-11-2010, 06:01 PM   #3
dave123 is offline
dave123
Jeeper
Vehicle(s): 1975 CJ5

dave123's Avatar

Join Date: Jul 2009
Location: Florida
Posts: 174
Images: 15
Thanks: 2
Thanked 5 Times in 4 Posts
Rep Power: 6 dave123 is on a distinguished road
Your module could be bad as well. try swapping in the old parts one by one (assuming you still have them).
__________________
Make mine a V8 with no top.



Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiFurl this Post!Stumble this Post!
Reply With Quote

Default Re: no spark

Old 06-11-2010, 07:15 PM   #4
54cj3b is offline
54cj3b
Jeeper
Vehicle(s): 1954 willys cj3b 1976 dj 5 rhd 1981 dj 5 rhd 1988 xj 1993 xj rhd 2006 kj

54cj3b's Avatar

Join Date: Apr 2010
Location: COLORADO
Age: 50
Posts: 277
Thanks: 0
Thanked 12 Times in 12 Posts
Rep Power: 5 54cj3b is on a distinguished road
after some research today I think I may have found the problem it may be the pick up in the distributor guess I'll find out tomorrow fingers crossed
__________________




Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiFurl this Post!Stumble this Post!
Reply With Quote

Default Re: no spark

Old 06-11-2010, 11:23 PM   #5
Jeff in Norcal is offline
Jeff in Norcal
New Jeeper
Vehicle(s): 84 CJ7, 258, T-176, AMC-20, D300, D30, 2.5" lift, Howell F.I., 32" MT's, ARB Rear Locker

Join Date: May 2010
Location: Northern CA
Posts: 25
Thanks: 0
Thanked 1 Time in 1 Post
Rep Power: 0 Jeff in Norcal is on a distinguished road
I agree with Dave. Check the module. I've had 2 go out in my older (80's) Chevy work trucks. Took one to Napa auto parts for the free electrical bench test to see if it was good. They checked it and said YES it was good. I spent hours going through everything else only to come back to the module. It WAS bad after all. They do crap out, so as Dave said, check that dude. Good possibility that's your problem.



Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiFurl this Post!Stumble this Post!
Reply With Quote

Default Re: no spark

Old 06-15-2010, 08:04 PM   #6
54cj3b is offline
54cj3b
Jeeper
Vehicle(s): 1954 willys cj3b 1976 dj 5 rhd 1981 dj 5 rhd 1988 xj 1993 xj rhd 2006 kj

54cj3b's Avatar

Join Date: Apr 2010
Location: COLORADO
Age: 50
Posts: 277
Thanks: 0
Thanked 12 Times in 12 Posts
Rep Power: 5 54cj3b is on a distinguished road
ran new wiring harness , new battery , new starter , solenoid , new coil , new dist shaft , new ecm , new alt , fuel pump , carb ,

checked for power at coil gets power but no spark ecm has power , pulled dist turned eng by hand to #1 set dist to #1 still nothing followed every step suggested and also every step in the big Chilton book this is on a 1976 dj5 258 need to get this thing going as its my wifes work vehicle theres no cps on this jeep
checked every thing in the book along with all suggestions everyone threw out this thing is becoming a royal pain in the ***
__________________


Last edited by 54cj3b; 06-15-2010 at 08:10 PM..



Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiFurl this Post!Stumble this Post!
Reply With Quote

Default Re: no spark

Old 06-16-2010, 08:46 PM   #7
Cheepjeep85 is offline
Cheepjeep85
Full Time Jeeper
Vehicle(s): 1985 Jeep CJ7, 258, t-176, D300, AMC20, D30

Cheepjeep85's Avatar

Join Date: Jan 2010
Location: Chickamauga, Ga
Age: 30
Posts: 2,603
Images: 57
Thanks: 52
Thanked 100 Times in 100 Posts
Rep Power: 7 Cheepjeep85 is on a distinguished road
PSSST...... HEI one wire keep it quiet don't tell nobody
__________________
http://m.urbandictionary.com/#define...al%20douchebag click it for a laugh



Digg this Post!Add Post to del.icio.usBookmark Post in TechnoratiFurl this Post!Stumble this Post!
Reply With Quote

Default Re: no spark

Old 06-16-2010, 09:17 PM   #8
tvince is offline
tvince
Junior Jeeper
Vehicle(s): 1978 CJ7

Join Date: Nov 2009
Location: KC MO
Age: 54
Posts: 68
Images: 3
Thanks: 0
Thanked 0 Times in 0 Posts
Rep Power: 5 tvince is on a distinguished road
I am in process of figuring out my ign issues as well do you have a full 12 v at plus side of coil my issue was the "Ballast Wire" breaking down / or up in resistance and after running a few mins the V at the coil would drop and start running rough below 10V and eventuaslly die at somewhere around 9.5V
Replaced 1.3 ohm wire with a .85 ohm "ballast resistor" and runs fine, But gonna start a new thread due to my inquiring mind regarding total resistance in the + coil line
I have 78 cj7 258 pointless dist and motocraft ign module
